Description
The Raycus 400W Pulsed Laser Pump Source Module is a high-power, industrial-grade laser diode array designed for integration into pulsed fiber laser systems used in marking, cleaning, and material processing. It delivers a stable 400W pulsed infrared output at 915nm, optimized for pumping high-power ytterbium-doped fiber lasers. This custom-built, all-in-one package includes the pump source, a pulse controller, and a constant-current driver board, making it ideal for use by trained professionals in controlled industrial or lab environments.
Core Features
-
High-Power Pulsed Output: 400W peak power at 915nm, ideal for pulsed fiber laser applications like marking, engraving, and surface cleaning.
-
All-in-One Package: Includes the pump source, pulse controller, and constant-current driver board for a complete, ready-to-integrate solution.
-
Customizable Performance: Supports PWM frequencies up to 100kHz and can be tailored to specific power levels with a typical 1-week lead time for custom orders.
-
Fiber-Coupled Delivery: Integrated 200μm core multimode fiber ensures precise, low-loss energy transfer to your target laser cavity.
-
Industrial-Grade Reliability: Built by Raycus, a trusted leader in fiber laser technology, for consistent performance and long lifespan.
Technical Specifications
| Parameter |
Details |
| Product Name |
Raycus 400W Pulsed Laser Pump Source Module – Customizable |
| Wavelength |
915nm ±1nm (infrared) |
| Power Output |
400W (peak pulsed power) |
| Fiber Core Diameter |
200μm (multimode) |
| Power Supply |
33V @ 22A (requires dedicated high-current power source) |
| Maximum PWM Frequency |
100kHz |
| Operating Temperature |
≤45°C (requires active cooling) |
| Dimensions |
~130mm × 75mm × 20mm (pump module) |
| Primary Applications |
Pulsed fiber laser marking, cleaning, and material processing; scientific research |
| Condition |
Custom-built and tested (as-new performance) |
| Operation Requirement |
Trained laser professionals only (requires thermal management expertise) |
SKU Details
| SKU |
Configuration |
|
| RAYCUS-400W-PULSE |
400W Pulsed Laser Pump Source + Controller + Driver |
|
| RAYCUS-400W-KIT |
Module + Thermal Compound + Power Cable |
|
| RAYCUS-CUSTOM-PULSE |
Custom Power/Frequency Pulsed Pump Source (1-week lead time) |
|
Why Choose This Raycus Pulsed Pump Source?
-
Trusted Performance: Raycus is a leading provider of fiber laser technology, ensuring exceptional reliability and output stability for industrial applications.
-
All-in-One Convenience: The complete package eliminates the need for separate component sourcing and complex integration.
-
Flexible Customization: Supports PWM up to 100kHz and can be built to your exact power requirements.
-
Cost-Effective Solution: Custom-built units deliver professional-grade performance at a competitive price point.
Important Safety & Usage Notes
-
Operator Training: This module must be handled and operated by trained laser professionals familiar with high-power diode safety protocols.
-
Thermal Management: A robust active cooling system is required to maintain temperatures ≤45°C during continuous operation.
-
Laser Safety: Always wear appropriate laser safety goggles (OD 4+ for 915nm) when operating this module. Never point the beam at people, animals, or reflective surfaces.
-
Custom Terms: This is a custom-built, as-is unit. It is tested for functional performance but sold without return or exchange.
-
Regulatory Compliance: Adhere to local laser safety regulations (e.g., FDA, CE) for your application. This module is not intended for consumer or recreational use.
