Description

The Professional Optical Power Meter is an essential precision instrument designed for accurate measurement of optical power output in laser systems, fiber optic communications, and photonic applications. Engineered with high sensitivity and broad wavelength coverage, this device provides reliable power readings for both laboratory research and industrial quality control. The meter features a user-friendly interface, robust construction, and comes complete with a portable battery pack for field measurements and on-site testing.

Key Features

  • High Accuracy Measurement: Precise optical power detection with minimal measurement error

  • Broad Wavelength Range: Compatible with various laser and optical sources

  • Portable Design: Integrated battery pack enables field use without external power

  • Large Display: Clear LCD screen showing real-time power readings

  • Multiple Measurement Units: Supports dBm, mW, W, and relative power measurements

  • Data Logging: Capability to record and store measurement data

  • Calibration Certificate: Factory calibrated with traceable standards

  • Durable Construction: Designed for reliable operation in laboratory and industrial environments

Technical Specifications

Optical Performance:

  • Wavelength Range: 800 nm to 1650 nm (extended range options available)

  • Measurement Range: 0.01 µW to 80 W (with appropriate attenuation)

  • Power Accuracy: ±5% of reading (typical)

  • Linearity: ±0.5% over full measurement range

  • Spectral Response: ±2% across specified wavelength range

  • Detector Type: Thermopile for high power, semiconductor for low power measurements

  • Detector Damage Threshold: > 80 W continuous wave

  • Response Time: < 2 seconds to 95% of final reading

Electrical & Physical Specifications:

  • Display: Backlit LCD with 4-digit resolution

  • Measurement Units: dBm, mW, W, relative dB

  • Battery Type: Rechargeable lithium-ion battery pack

  • Battery Life: > 8 hours continuous operation

  • Charging Time: < 3 hours for full charge

  • Charging Interface: USB-C charging port

  • Data Interface: USB 2.0 for data transfer

  • Operating Temperature: 0°C to 50°C

  • Storage Temperature: -20°C to 70°C

  • Relative Humidity: 0% to 80% (non-condensing)

  • Dimensions (Main Unit): 150 mm × 80 mm × 35 mm

  • Weight (Main Unit): 280 grams

  • Dimensions (Battery Pack): 100 mm × 60 mm × 25 mm

  • Weight (Battery Pack): 180 grams

Connector & Interface:

  • Optical Input: Standard FC/PC, SC/PC, ST/PC adapters included

  • Adapter Options: Available for various fiber connector types

  • Electrical Output: USB data port for PC connection

  • Mounting: Standard 1/4"-20 tripod thread on base

SKU Details

Standard Packages:

  • SKU-OPM-80W-BASIC: Basic package with 80W optical power meter, single detector head, battery pack

  • SKU-OPM-80W-PRO: Professional package with multiple detector heads, calibration certificate, carrying case

  • SKU-OPM-80W-ENTERPRISE: Enterprise package with all accessories, extended calibration, dedicated software

Detector Options:

  • SKU-DET-HIGH-POWER: High power detector (10W-80W range)

  • SKU-DET-MID-POWER: Mid power detector (100mW-10W range)

  • SKU-DET-LOW-POWER: Low power detector (0.01µW-100mW range)

  • SKU-DET-EXTENDED-WL: Extended wavelength detector (400nm-1800nm)

Accessory Packages:

  • SKU-ACC-ADAPTERS: Set of optical adapters (FC, SC, ST, LC connectors)

  • SKU-ACC-CALIBRATION: Annual recalibration service

  • SKU-ACC-SOFTWARE: Advanced measurement and analysis software

  • SKU-ACC-CARRYING-CASE: Professional padded carrying case

  • SKU-ACC-ATTENUATORS: Set of optical attenuators for extended range

Applications

  • Laser power measurement and calibration

  • Fiber optic communication system testing

  • Medical laser equipment verification

  • Industrial laser process monitoring

  • Research and development laboratories

  • Telecommunications network maintenance

  • Educational institution laboratories

  • Manufacturing quality control

  • Field service and installation verification

  • Photovoltaic system testing

Measurement Capabilities

  • Continuous Wave Measurement: Accurate measurement of CW laser sources

  • Pulsed Laser Measurement: Capability to measure average power of pulsed sources

  • Relative Power Measurement: Comparison measurements between different sources

  • Long-term Stability Monitoring: Continuous monitoring of optical power stability

  • Spectral Power Density: Measurement across specific wavelength ranges

Calibration & Accuracy

  • Factory Calibration: Each unit calibrated against NIST-traceable standards

  • Calibration Interval: Recommended annual recalibration

  • Calibration Points: Multiple points across measurement range

  • Calibration Wavelengths: Standard wavelengths: 850nm, 980nm, 1064nm, 1310nm, 1550nm

  • Certificate: Includes detailed calibration certificate with measurement uncertainty

Safety Features

  • Overload Protection: Automatic protection against excessive optical power

  • Reverse Polarity Protection: Protection against incorrect battery installation

  • Temperature Monitoring: Automatic shutdown in case of overheating

  • Low Battery Warning: Visual and audible low battery indication

  • Safe Storage: Protective caps for optical connectors

Package Includes

  • 1 × Optical Power Meter Main Unit

  • 1 × Rechargeable Battery Pack

  • 1 × Standard Detector Head (specify range)

  • 1 × Set of Optical Adapters (FC, SC, ST)

  • 1 × USB Charging Cable

  • 1 × USB Data Cable

  • 1 × User Manual

  • 1 × Quick Start Guide

  • 1 × Basic Calibration Certificate

  • 1 × Protective Carrying Pouch

Software & Connectivity

  • PC Software: Data logging and analysis software (Windows/Mac compatible)

  • Mobile App: Bluetooth connectivity option for smartphone control

  • Data Export: CSV, Excel, and PDF export capabilities

  • Remote Control: Ethernet/RS-232 options for remote operation

  • API Access: Programmatic control for automated testing systems

For detailed application guidance, custom calibration requirements, or technical specifications for specific measurement scenarios, please consult our technical documentation or contact our measurement engineering team. We provide comprehensive support for optical power measurement applications across research, industrial, and telecommunications environments.
