Professional High-Precision CNC Machining Platform | 6061-T6 Aluminum Alloy Monolithic Body | 0.01mm Repeatability
Key Selling Points (Bullet Points)
-
Monolithic & Rigid Foundation: Machined from a solid 12/15mm thick 6061-T6 aluminum plate in one CNC setup, eliminating assembly error and ensuring long-term stability.
-
Precision Drive System: Features 20mm linear rails and 1605 ball screws for smooth, rigid motion and accurate power transmission.
-
Superior Accuracy: Achieves repeatability as high as 0.01-0.02mm with precision alignment slots. Base machining accuracy is within 0.05mm.
-
Flexible Configuration: Offered as a "Mechanical Kit" or "Full Set" (with 57 stepper motor). Motor mount is customizable for easy integration.
Product Description
1. One-Piece Monolithic Body: Where Precision Begins
The core of this platform is its monolithic body, machined from 12mm and 15mm thick 6061-T6 aluminum in a single CNC operation. This process eliminates cumulative tolerance and stress deformation from multi-part assembly, providing an absolutely stable, zero-deflection base essential for maintaining ultra-high precision. Key mating surfaces feature precision alignment slots for guaranteed rigidity.
2. Precision Motion System: Smooth, Stable, and Accurate
-
Linear Guides: Equipped with 20mm wide heavy-duty linear rails and dual blocks for high load capacity and torsional rigidity, ensuring smooth operation even at high speeds.
-
Drive System: Utilizes a 1605 ball screw (16mm diameter, 5mm lead) for high transmission efficiency and precise linear motion control.
-
Power Unit: Includes a high-performance 57 stepper motor (38mm flange). The motor mount is designed for flexibility and can be customized to fit your specific motor or spatial requirements.
3. Performance & Accuracy: Built for Demanding Applications
-
Machining Accuracy: The overall machining tolerance is tightly controlled within 0.05mm.
-
Core Performance: The integration of precision components and monolithic construction enables exceptional repeatability of 0.01mm to 0.02mm. This performance can be further enhanced based on specialized process requirements.
4. Flexible Purchase Options
To suit different project needs, we offer two configurations:
-
Mechanical Kit: Includes the complete mechanical assembly (body, rails, ball screw assembly), ideal for integrators who prefer to source their own motors and drives.
-
Full Set: Includes the Mechanical Kit paired with a matching 57 stepper motor for faster setup.
Technical Specifications Table
