Description
This MAX Chuangxin 350–360W fiber laser pump diode module is a custom-engineered, high-power component designed for industrial laser cutting, welding, and system upgrades. With a tested output of ~360W, it delivers stable, high-efficiency performance and offers exceptional modification flexibility, making it ideal for maintenance teams, laser system integrators, and OEM manufacturers seeking a cost-effective alternative to new OEM modules.
📊 Key Features & Specifications
-
Brand: MAX
-
Power Output: 350W rated, ~360W tested (verified with video proof)
-
Wavelength: 976nm (optimized for fiber laser pumping efficiency)
-
Electrical Specifications:
- Operating Voltage: 21.5V DC
- Maximum Operating Current: 30A (critical: do not exceed)
-
Fiber Configuration:
- Core Diameter: 200μm
- Effective Focus Range: Customizable on request
-
Mechanical Dimensions: 55 × 33 mm (approximate)
-
Form Factor: Rugged aluminum heat sink package for superior thermal management
-
Condition: Custom pulled unit, tested with video verification before shipment
-
Quality Assurance: Each module is labeled with a unique serial number for traceability
🛠️ SKU Details
| SKU Code |
Configuration |
Quantity |
| MAX-360W-976-BARE |
360W, 976nm, bare fiber output |
In stock (limited) |
| MAX-360W-976-SMA |
360W, 976nm, SMA905 quick-connect |
In stock (limited) |
| MAX-360W-976-ARMORED |
360W, 976nm, metal armored fiber |
Made-to-order |
| MAX-360W-976-LENS |
360W, 976nm, armored fiber + focus lens |
Made-to-order |
🎯 Applications
- High-power laser cutting of thick metals and composites
- Precision laser welding and cladding
- Laser system upgrades and modification projects
- Custom high-power laser system integration
- Replacement pump source for MAX fiber laser generators
- Industrial laser system maintenance and repair
💡 Why Choose Our MAX 360W Pump Module?
-
Verified High Power: Each module undergoes full testing (with video proof) to confirm ~360W output stability
-
Modification Flexibility: Easily adapted to custom laser system designs and upgrades
-
Durable Construction: Rugged aluminum heat sink ensures excellent thermal management for long-term reliability
-
Critical Safety Compliance: Pre-tested to ensure current does not exceed 30A (prevents thermal damage)
-
Cost-Effective: Significant savings compared to new OEM modules, with equivalent performance
-
Fast Shipping: Dispatched within 48 hours from our Zhejiang warehouse, with global delivery options
📦 Package Includes
1 x MAX Chuangxin 350–360W Fiber Laser Pump Diode Module (as per your SKU selection)
1 x Protective fiber cable (yellow or armored, based on configuration)
1 x Test video link (verifying ~360W power output)
1 x Anti-static packaging for safe handling
⚠️ Important Notes
-
Critical Operation Rule: Current must NOT exceed 30A. Overcurrent causes irreversible damage to the module.
-
Non-Returnable Policy: This is a custom pulled unit, sold as-is. No returns or exchanges are accepted after delivery.
-
Inspection Requirement: Inspect the package immediately upon receipt. Report damage before signing for delivery.
-
Technical Expertise: Installation requires specialized knowledge of high-power laser systems and thermal management.
-
Cosmetic Condition: This is a used component; minor cosmetic wear is typical but does not affect functionality.
