Name: High-power quartz water-cooled beam expander for laser welding and cutting machines
Brand: LaserOne
Price: 149.0 USD
Availability: InStock

Description

AquaCool Pro Series High-Power Water-Cooled Beam Expanders

2. Model Numbering Convention: Clear "Series-Magnification" structure.

Model Examples:

AquaCool Pro-3X
AquaCool Pro-6X
AquaCool Pro-10X

Product Detail Page Framework

1. Core Headline

"AquaCool Pro Series: Industrial-Grade Cooling for Kilowatt Laser Applications" Engineered specifically for high-power laser welding and cutting systems, these water-cooled beam expanders feature durable quartz optics and robust construction to maintain stability under continuous industrial operation.

2. Key Features

Active Water-Cooling System
- Icon: ❄️
- Text: Integrated cooling channels effectively dissipate heat, ensuring stable performance and protecting optics under multi-kilowatt laser power.
High-Power Quartz Optics
- Icon: 💎
- Text: Fused quartz lenses withstand intense power densities at 808nm, 915nm, 980nm, and 1064nm, maintaining beam quality in demanding environments.
Industrial-Ready Construction
- Icon: 🏭
- Text: 42mm diameter housing with M22×0.75 threads provides secure integration into industrial laser heads and robotic systems.
Immediate Availability
- Icon: 🚀
- Text: 2X, 3X, 4X, 5X, and 6X models in stock for rapid deployment in production environments.

3. Detailed Specifications

Parameter Category	Specifications
Product Series	AquaCool Pro Series
Available Magnifications	In Stock: 2X, 3X, 4X, 5X, 6X Available: 8X, 10X, 15X
Housing Diameter	42 mm
Housing Length	70 mm (excluding adjustment threads)
Lens Sizes	Objective: 28 mm, Eyepiece: 14 mm
Connection Thread	M22 × 0.75
Wavelength Range	808 nm, 915 nm, 980 nm, 1064 nm
Cooling Method	Water Cooling

4. Application Scenarios

High-Power Laser Welding
- Caption: "Maintains beam quality and focus position stability during extended welding cycles, crucial for automotive and heavy industry applications."
Industrial Laser Cutting
- Caption: "Ensures consistent cutting performance in continuous operation, with thermal management preventing focal shift during long production runs."
Additive Manufacturing
- Caption: "Provides reliable beam expansion for laser cladding and 3D printing applications where thermal stability is critical to process quality."

5. Selection & Ordering Guide

Title: Configure Your Industrial Beam Expander

Selection Steps:

Select Magnification: Choose from in-stock 2X-6X models or select 8X-15X for extended range requirements
Verify Integration: Confirm M22×0.75 threading and 42mm diameter compatibility with your laser system
Plan Cooling Connection: Ensure appropriate water cooling fittings and flow rates are available

Call to Action:

Industrial solutions in stock! Order 2X-6X magnifications for immediate shipment. Contact our engineering team for custom configurations or application-specific recommendations.
