Name: 532nm 632.8nm 808nm 915nm 1064nm Laser beam expanding lens - Type B
Brand: LaserOne
Price: 79.0 USD
Availability: InStock

Description

BeamExpand Pro B-Series Multi-Wavelength Laser Beam Expanders

2. Model Numbering Convention: Clear "Series-Magnification-Thread" structure.

Model Examples:

BeamExpand Pro-B-3X-M22
BeamExpand Pro-B-10X-M26
BeamExpand Pro-B-15X-M22

Product Detail Page Framework

1. Core Headline

"BeamExpand Pro B-Series: Versatile Performance Across Multiple Wavelengths" Engineered for flexibility, this B-Series beam expander supports essential wavelengths from visible to IR. With 1.5X-20X magnifications in stock and dual thread options, it's the ideal solution for diverse laser applications.

2. Key Features

Multi-Wavelength Optimized
- Icon: 🌈
- Text: Precisely calibrated for 532nm, 632.8nm, 808nm, 915nm, and 1064nm lasers, ensuring reliable performance across common DPSS and diode laser lines.
Comprehensive Magnification Range
- Icon: 📊
- Text: 1.5X to 20X models readily available, covering applications from subtle beam sizing to high-magnification expansion. Common ratios like 2X, 3X, 5X, 6X, 8X, 10X, and 15X are in stock for immediate delivery.
Dual Thread Compatibility
- Icon: 🔩
- Text: Choose between M22×0.75 and M26×0.75 mounting threads for seamless integration with various optical setups and laser systems.
Precision Optical Design
- Icon: ⚙️
- Text: Features 16mm input and 30mm output lenses, handling input beams up to 12mm and delivering high-quality 28mm output beams with minimal wavefront distortion.

3. Detailed Specifications

Parameter Category	Specifications
Product Series	BeamExpand Pro B-Series
Supported Wavelengths	532nm, 632.8nm, 808nm, 915nm, 1064nm
Available Magnifications	In Stock: 1.5X, 2X, 2.5X, 3X, 4X, 5X, 6X, 8X, 10X, 15X, 20X Custom: Other ratios available (Contact Support)
Max Input Beam Diameter	12 mm
Max Output Beam Diameter	28 mm
Lens Sizes	Input: 16 mm, Output: 30 mm
Mounting Threads	M22×0.75, M26×0.75

4. Application Scenarios

Laboratory & Research Setup
- Caption: "Ideal for multi-wavelength experimental arrangements in research labs, providing consistent beam expansion across different laser sources."
Industrial Marking & Engraving
- Caption: "Perfect for integration into laser marking systems, improving beam quality and enabling finer feature resolution."
Medical & Aesthetic Laser Systems
- Caption: "Suitable for various medical laser applications where specific wavelength beam conditioning is required."

5. Selection & Ordering Guide

Title: Configure Your Multi-Wavelength Beam Expander

Selection Steps:

Select Magnification: Choose from our extensive in-stock range (1.5X-20X)
Choose Mounting Thread: Specify either M22×0.75 or M26×0.75 based on your system requirements
Confirm Wavelength: Verify your operating wavelength matches our optimized parameters

Call to Action:

Multiple magnifications in stock! Select your preferred magnification and thread type for immediate ordering. Contact our technical team for assistance with custom magnification requirements or specific wavelength optimization questions.

532nm 632.8nm 808nm 915nm 1064nm Laser beam expanding lens - Type B

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

BeamExpand Pro B-Series Multi-Wavelength Laser Beam Expanders

2. Model Numbering Convention: Clear "Series-Magnification-Thread" structure.

Model Examples:

BeamExpand Pro-B-3X-M22
BeamExpand Pro-B-10X-M26
BeamExpand Pro-B-15X-M22

Product Detail Page Framework

1. Core Headline

"BeamExpand Pro B-Series: Versatile Performance Across Multiple Wavelengths" Engineered for flexibility, this B-Series beam expander supports essential wavelengths from visible to IR. With 1.5X-20X magnifications in stock and dual thread options, it's the ideal solution for diverse laser applications.

2. Key Features

Multi-Wavelength Optimized
- Icon: 🌈
- Text: Precisely calibrated for 532nm, 632.8nm, 808nm, 915nm, and 1064nm lasers, ensuring reliable performance across common DPSS and diode laser lines.
Comprehensive Magnification Range
- Icon: 📊
- Text: 1.5X to 20X models readily available, covering applications from subtle beam sizing to high-magnification expansion. Common ratios like 2X, 3X, 5X, 6X, 8X, 10X, and 15X are in stock for immediate delivery.
Dual Thread Compatibility
- Icon: 🔩
- Text: Choose between M22×0.75 and M26×0.75 mounting threads for seamless integration with various optical setups and laser systems.
Precision Optical Design
- Icon: ⚙️
- Text: Features 16mm input and 30mm output lenses, handling input beams up to 12mm and delivering high-quality 28mm output beams with minimal wavefront distortion.

3. Detailed Specifications

Parameter Category	Specifications
Product Series	BeamExpand Pro B-Series
Supported Wavelengths	532nm, 632.8nm, 808nm, 915nm, 1064nm
Available Magnifications	In Stock: 1.5X, 2X, 2.5X, 3X, 4X, 5X, 6X, 8X, 10X, 15X, 20X Custom: Other ratios available (Contact Support)
Max Input Beam Diameter	12 mm
Max Output Beam Diameter	28 mm
Lens Sizes	Input: 16 mm, Output: 30 mm
Mounting Threads	M22×0.75, M26×0.75

4. Application Scenarios

Laboratory & Research Setup
- Caption: "Ideal for multi-wavelength experimental arrangements in research labs, providing consistent beam expansion across different laser sources."
Industrial Marking & Engraving
- Caption: "Perfect for integration into laser marking systems, improving beam quality and enabling finer feature resolution."
Medical & Aesthetic Laser Systems
- Caption: "Suitable for various medical laser applications where specific wavelength beam conditioning is required."

5. Selection & Ordering Guide

Title: Configure Your Multi-Wavelength Beam Expander

Selection Steps:

Select Magnification: Choose from our extensive in-stock range (1.5X-20X)
Choose Mounting Thread: Specify either M22×0.75 or M26×0.75 based on your system requirements
Confirm Wavelength: Verify your operating wavelength matches our optimized parameters

Call to Action:

Multiple magnifications in stock! Select your preferred magnification and thread type for immediate ordering. Contact our technical team for assistance with custom magnification requirements or specific wavelength optimization questions.
