Professional-Grade Optical Fiber Patch Cable for Laser Systems – Single Mode & Multimode Options

The Professional-Grade Optical Fiber Patch Cable is engineered to deliver reliable, high-performance signal transmission for laser systems, medical equipment, telecommunications, and industrial applications. Designed with precision alignment and durable construction, these patch cables ensure minimal signal loss, excellent mechanical stability, and long-term reliability in demanding environments. Available in both single-mode and multimode configurations with various connector types, these cables are essential components for any optical system requiring consistent, high-quality signal delivery.

Key Features

• Low Insertion Loss: Premium connectors ensure minimal signal attenuation

• High Return Loss: Optimized for maximum signal integrity

• Durable Construction: Reinforced outer jacket protects against physical stress and environmental factors

• Precision Polish: PC (Physical Contact), UPC (Ultra Physical Contact), and APC (Angled Physical Contact) polish options available

• Temperature Resistant: Stable performance across wide temperature ranges

• Flexible Design: Maintains performance even with repeated bending and movement

• Standard Compliance: Meets industry standards for optical performance and reliability

Technical Specifications

Fiber Types:

• Single-Mode Fiber (SMF):

  • Wavelength: 1310nm, 1550nm

  • Core Diameter: 9/125μm

  • Attenuation: ≤ 0.36 dB/km @ 1310nm, ≤ 0.22 dB/km @ 1550nm

  • Bandwidth: Excellent for long-distance, high-bandwidth applications

• Multimode Fiber (MMF):

  • Wavelength: 850nm, 1300nm

  • Core Diameter: 50/125μm or 62.5/125μm options

  • Attenuation: ≤ 3.0 dB/km @ 850nm, ≤ 1.0 dB/km @ 1300nm

  • Bandwidth: Ideal for short to medium distance applications

Cable Construction:

• Outer Jacket: LSZH (Low Smoke Zero Halogen) or PVC options

• Strength Members: Aramid yarn reinforcement

• Inner Structure: Loose tube or tight buffer construction

• Diameter Options: 2.0mm, 3.0mm, and custom diameters available

• Color Coding: Standard TIA-598 color coding for easy identification

Connector Options:

• LC/UPC: Single-mode and multimode, low insertion loss

• SC/UPC: Standard connector for telecom and datacom

• FC/APC: Angled polish for minimal back reflection

• ST/UPC: Bayonet-style connector for multimode systems

• MTP/MPO: Multi-fiber connectors for high-density applications

• E2000: High-performance connector with integrated dust cap

Performance Specifications:

• Insertion Loss: ≤ 0.3 dB (typical), ≤ 0.5 dB (maximum)

• Return Loss: ≥ 50 dB (UPC), ≥ 60 dB (APC)

• Operating Temperature: -20°C to +70°C

• Storage Temperature: -40°C to +85°C

• Minimum Bend Radius: 10× cable diameter (under load), 15× cable diameter (no load)

• Tensile Load: ≤ 100N (during installation), ≤ 40N (during operation)

SKU Details

By Fiber Type & Length:

• SKU-PC-SM-1M: Single-mode, 1 meter length

• SKU-PC-SM-2M: Single-mode, 2 meter length

• SKU-PC-SM-3M: Single-mode, 3 meter length

• SKU-PC-MM-1M: Multimode (50/125), 1 meter length

• SKU-PC-MM-2M: Multimode (50/125), 2 meter length

• SKU-PC-MM-3M: Multimode (50/125), 3 meter length

• SKU-PC-MM62-2M: Multimode (62.5/125), 2 meter length

By Connector Type:

• SKU-LC-LC-2M: LC to LC connectors, 2 meter length

• SKU-SC-SC-2M: SC to SC connectors, 2 meter length

• SKU-FC-FC-2M: FC to FC connectors, 2 meter length

• SKU-ST-ST-2M: ST to ST connectors, 2 meter length

• SKU-LC-SC-2M: LC to SC hybrid connector, 2 meter length

• SKU-MTP-12-3M: MTP 12-fiber connector, 3 meter length

Custom Length Options:

• SKU-CUSTOM-LENGTH: Custom lengths from 0.5m to 100m

• SKU-CUSTOM-CONN: Custom connector combinations

• SKU-BULK-REEL: Bulk fiber on reels for custom termination

Applications

• Laser cutting and engraving system connections

• Medical laser equipment

• Fiber optic telecommunications

• Data center interconnections

• Industrial automation and control systems

• Military and aerospace optical systems

• Research laboratory instrumentation

• Broadcast and audio-visual systems

• Security and surveillance systems

Installation & Handling

• Cleaning: Use approved fiber optic cleaning tools and solutions

• Inspection: Visual inspection recommended before connection

• Handling: Avoid excessive bending or twisting

• Storage: Keep in protective packaging when not in use

• Connecting: Ensure proper alignment before securing connectors

• Testing: Regular testing recommended for critical applications

Quality Assurance

• 100% optical performance testing before shipment

• Compliance with IEC, TIA/EIA, and ISO standards

• Traceable manufacturing and testing records

• Environmental testing for temperature and humidity resistance

• Mechanical testing for durability and reliability

Package Includes

• 1 × Optical fiber patch cable (specified length and connectors)

• Protective dust caps on all connectors

• Product specification sheet

• Basic handling and cleaning guide

Customization Services

• Custom connector polishing (PC, UPC, APC)

• Special jacket materials (armored, outdoor-rated, etc.)

• Specific color coding requirements

• OEM branding and packaging

• Volume pricing for bulk orders

For technical specifications, custom configurations, or assistance selecting the appropriate patch cable for your application, please contact our technical support team. We provide expert guidance for system integration, performance optimization, and custom optical solutions tailored to your specific requirements.
